Product Details
+
Features :
- Warranty : 6 months (limited to manufacturer's fault and does not cover motor burn)
- Oil Lubricated, cabinet configuration, quality parts used
- Low noise (as low as 60 dBA - Measured at 3m away from compressor at a open area.)
- Star-delta Starer Alternative for big power units
- Anti-vibration design for both transport and operation
- Integrated control board with auto start-stop & malfunction protection. (visible operations)
- Belt Adjustment device that are CE certified.
Specifications :
- Motor :
- Power : 7,500 W
- Horsepower : 10 Hp
- Voltage : 415V (50Hz)
- No Load Speed : 859 rpm
- Piston Cylinder :
- No. x Diameter : 3 cylinder x 90mm
- Stroke length : 70mm
- Air Delivery : 900L/min (32 CFM)
- Air Pressure : 0.8 Mpa (115 PSI)
- Air Tank size : 6 litre
- Dimensions (L x W x H) : 85 x 78 x 112 cm
- Gross Weight : 295 kg
